WELLWIN's Digital Binoculars Camera with binoculars + camera ,two-in-one function. The telescope function of the digital binoculars camera features an excellent 12X optical zoom and 8X digital zoom. Whether it's wildlife hidden deep in the jungle or an exciting sporting event in the distance, it can clearly bring the target closer with rich and fine details. High-quality lenses and advanced optical technology effectively reduce chromatic aberration and aberration, ensuring that users get a clear, sharp and lifelike visual experience.
Its camera function, on the other hand, allows moments of excitement to be frozen for eternity. When capturing heartwarming images, the 48MP picture resolution and 2.5K video resolution transform the beauty or precious moments in front of you into high-quality digital images. These images can not only be instantly viewed on the camera screen, but can also be easily transferred to a computer or other device for post-processing, sharing or saving.
This two-in-one functional design brings a number of advantages. Firstly, it greatly simplifies and lightens the burden of the equipment one needs to carry when observing and recording. Secondly, it avoids the regret of not being able to record the wonderful moments observed with traditional telescopes in a timely manner. Moreover, digital telescope cameras are usually equipped with rich functions such as smart focus, continuous shooting mode, etc., which meet the diversified needs of different scenes and users.
For more detailed operating instructions, please see below.
Care and maintenance
● Clean the product only with a dry or slightly damp, lint-free cloth.
● Do not use abrasive cleaners to clean the unit.
● Digital binocular is a high-precision optical instrument, so in order to avoid damage, please avoid the following practice:
● Use the binocular in ultra-high or ultra-low temperature.
● Keep it or use it in moist environment for long time.
● Use it in rainfalls or in water.
● Deliver or use it in strongly shocking environment.
How to Use the binocular
You can use binoculars like any other pair of binoculars. Place your eyes correctly against the rubber, adjust the spacing of the 2 vision tubes and use the dial located above to focus. You can also turn the dial directly on the right side viewfinder at the level of the rubber where you place your eyes.
How to use the digital recording camera
1.Charging the battery
Connect to the camera to the AC adaptor, using the dedicated USB cable supplied.
The camera can be charged by connecting the camera to a computer using the dedicated USB cable.
*Charging indicator: red light-charging, red light Off -fully charged.
2.Inserting a memory card
Insert the Micro SD card into the Micro SD card slot.
3.Turn on the Binocular
Press and hold the Power button until the LCD screen turns on, the binoculars are ready to take photos or videos.
Select the mode
When the blue LED of the binocular is lit, press the Mode button to switch between: Video; Photo; Replay
1)Photo Mode
2)Self Timer
3)Photo Burst
4)Zoom level
5)Photos Remaining
6)Photo Size(Resolution)
7)Battery Level
8)Current Time
9)Current Date
10)Memory Card Loaded
11)Exposure Value
1)Video Mode
2)Zoom level
3)Recording Time Elappsed
4)Video Size(Resolution)
5)Battery Level
6)Current Time
7)Current Date
8)Memory Card Loaded
9)Exposure Value
- In video mode: Press the camera button to start shooting. Press again to stop filming.
- In photo mode: Press the camera button to take a picture.
Press as many times as you want to take a photo.
- In replay mode use the Left and Right buttons to select the file you want to watch and press the Camera button to play a video on the screen.
Note: For best picture quality, hold the binoculars firmly or use a tripod to stabilize during recording.
4.Turn off the Binocular
Press and hold the Power button until the screen off.
5.Video settings
Turn on the binoculars,Press the Menu button and then use the Left and Right buttons to navigate the resolution menu. Press the Camera button to enter the sub-menus and set the video resolution ,press Camera Button to confirm your choices and exit settings, press the Menu button or Mode button to return to the normal screen:
| Video Size |
2.5K UHD
1080P FHD
1080P
720P
|
| Loop Recording |
Off
1 Minute
2 Minute
3 Minutes
5 Minutes
|
| Video Rate |
Normal
Slow
Fast
|
| Time Stamp |
Off
On
|
6.Photo settings
Turn on the binoculars, and select the photo mode.
Press the Menu button and then use the Left and Right buttons to navigate the Photo menu. Press the Camera button to enter the sub-menus and confirm your choices and exit settings, press the Menu or Mode button to return to the normal screen:
| Photo Menu |
Sub Menu |
| Photo size |
48M
30M
25M
20M
10M
8M
5M
3M
|
| Self Timer |
Off
2Seconds
5Seconds
10Secondsr
|
| Photo Burst |
Off
3 Photos
|
7.Replay settings
Turn on the binoculars, and select the replay mode.
Press the Mode button to enter reply mode and then use the Left or Right buttons to navigate the photo or video file. Press the camera button to replay the video, press the Menu button and camera button to delete the file ,press Mode button to return normal screen:
| Delete |
Delete Current
Delete All
|
Cancel
OK
|
8.Exposure Settings
This function can be automatically set to EVA when the light is sufficient. In low light conditions, EV can be adjusted from +2 to - 2, then adjust the peripheral light of the photographed object to achieve the clearest state.
Turn on the binoculars, in Video or photo mode, press Menu button ,use Left or Right buttons to navigate to exposure setting project,press Camera button to enter exposure setting submenu.Set exposure value using Left or Right buttons,press camera button to confirm setting and exit.
| Exposure Value Setting |
+2.0,+5/3,+4/3,+1.0,+2/3, +1/3,+0.0,-1/3,-2/3,-1.0,-4/3,-5/3,-2.0 |
9.System settings
Turn on the binoculars and press the Menu button to open setting menu and then use the Left or Right button to navigate the menu. Press the camera button to enter the sub-menus and confirm your choices. To exit settings, press the Menu button or Mode button to return to the normal screen:
| Screen Brightness |
1 2 3 4 5 6 7 8 level |
| Screen Saver |
Off; 1 Minute; 2 Minutes; 3 Minutes |
| Auto Power-Off |
Off; 1 Minute; 3 Minutes; 5 Minutes |
| Language |
English,Japanese, French, Spanish, Portuguese, German,Korean, Italian, Chinese, Russian, Arabic |
| Volume |
0 1 2 3 4 5 6 7 8 Level |
| Format Card |
Cancel
Format
|
| Date/Time Set |
Year/Month/Day
Hour : minute:second
|
| Restore Default |
Cancel
OK
|
Connect to the PC
→Connect the camera to PC by using USB cable and turn on the camera, the PC can read the files in this camera.
10.Reset
When the product stops responding due to misuse or other unknown reasons and cannot be connected to a computer, please reset it by pressing the “Reset” button . The product stops and resets.
The recorded files on the MicroSD are not affected. Even the done settings are not influenced.
